Product Features

  • Tamper resistant, heavy-duty construction
  • Constructed entirely of stainless steel for strength and corrosion resistance
  • Static strength 1,500 lbs
  • Dynamic strength 70 ft-lbs
  • Endurance rating 1,000,000 cycles
  • Horizontally adjustable keeper allows for door and frame misalignment
  • 1/2" keeper depth (310-2)
  • Non-handed
  • Fail secure (standard)
  • Plug-in connector
Application
  • Adjustability : Horizontal
  • Surface Mounting : Cutting required
  • Frame Material : Metal|Wood
  • Latchbolt Accommodation : 1/2" - 1"
Electrical
  • Voltage : 12|24
  • Monitoring Installation : Factory Configured
  • Monitoring Options : Latchbolt and locking cam monitor with auxiliary switch
Strength & Durability
  • Endurance (cycles) : 1,000,000
  • Dynamic Strength (ft-lbs) : 70
  • Tamper Resistant : Yes
  • Fail Safe or Fail Secure : Fail Secure|Fail Safe
General Specifications
  • Warranty : SecuriCare five-year, no fault, no questions asked warranty
  • Lock Type : Cylindrical Lock|Mortise Lock|Mortise Lock with Deadbolt
Certifications
  • ANSI/BHMA A156.31, Grade 1
  • RoHS Compliant
  • UL 1034 burglary-resistant listed
  • UL 10C - Standard for Positive Pressure Fire Tests of Door Assemblies
  • UL294 Listed
General Specification
  • Fire Rating ~ Double Door : 3 Hour (Fail Secure Only)
  • Fire Rating ~ Single Door : 3 Hour (Fail Secure Only)
