Product Features

• Stainless steel construction
• Tamper resistant
• Static strength 1,500 lbs. (791 and 792 options)
• Dynamic strength 70 ft-lbs. (791 and 792 options)
• Static strength 1,000 lbs. (783S, 786S and 789S options)
• Dynamic strength 50 ft-lbs. (783S, 786S and 789S options)
• Endurance 1,000,000 cycles
• Field selectable fail secure/fail safe
• Accommodates preload (up to 15 lbs. fail secure only)
• Horizontal adjustment
• Non-handed
• Internally mounted solenoid
• Strike body depth 1-11/16"
• Plug-in connector
• Trim enhancer (791 and 792 options)
• Pocket adapter (786S and 789S options)
• Dual voltage 12 or 24 VDC/VAC
